Overview
Engineered for industries where reliability is non-negotiable, our waterproof liquid silicone die delivers precision-molded LSR (Liquid Silicone Rubber) components that seal, protect, and perform under the most aggressive conditions. From automotive sensor housings and medical device enclosures to consumer electronics and industrial waterproof connectors, our tooling solutions consistently achieve IP67–IP68-rated waterproof performance.
Unlike conventional compression molding, our liquid injection molding (LIM) process uses vacuum-assisted injection to eliminate air bubbles and micro-defects, producing a seamless, high-density finish that guarantees zero-leakage performance. Each waterproof liquid silicone die is engineered to produce parts with dimensional tolerances as tight as ±0.01mm, ensuring your components fit perfectly every time.
Why Choose Our Waterproof Liquid Silicone Die?
Uncompromising Material Integrity – We utilize high-purity, platinum-cured LSR with proven resistance to water, oxidation, UV, ozone, and extreme temperatures ranging from -60°C to +230°C. The material maintains its elasticity and sealing force even after millions of compression cycles, making it ideal for long-term waterproof applications.
Precision Tooling for Zero-Defect Production – Our molds are fabricated using aerospace-grade tool steels and advanced CNC machining, with mirror-polished cavity surfaces (Ra 0.1) that minimize material adhesion and ensure easy part ejection. Optimized thermal management and cold-runner systems prevent premature curing and reduce material waste.
Scalable, High-Efficiency Manufacturing – With automated injection molding systems and multi-cavity configurations, we deliver consistent quality across high-volume production runs while reducing cycle times. Every component undergoes 100% automated pressure testing and 3D laser dimensional inspection before shipment.
Industry-Grade Compliance – Our waterproof liquid silicone die supports production of parts that meet FDA, RoHS, REACH, and ISO 10993 standards, with medical-grade material options available. Full material traceability and batch tracking ensure complete quality accountability.
Key Applications
Automotive: Battery module seals, connector gaskets, sensor housings
Medical Devices: Surgical instrument seals, endoscopic camera waterproofing
Consumer Electronics: Smartwatch seals, wearable device waterproofing
Industrial: Underwater sensors, IP68-rated enclosures, heavy-duty sealing components
Technical Specifications
|
Parameter |
Specification |
|
Material |
Platinum-cured LSR (FDA/ISO 10993 grades available) |
|
Hardness Range |
20–80 Shore A |
|
Operating Temperature |
-60°C to +230°C |
|
Dimensional Tolerance |
±0.01mm typical |
|
Waterproof Rating |
IP67–IP68 achievable |
|
Surface Finish |
Ra 0.1 mirror polish |
Frequently Asked Questions (FAQ)
Q: What is the difference between a waterproof liquid silicone die and a standard rubber mold?
A: A waterproof liquid silicone die is specifically engineered for LSR injection molding, which uses platinum-cured liquid silicone rather than solid rubber. This process delivers superior dimensional accuracy, faster cycle times, and better material consistency compared to traditional compression molding. The result is parts with zero-leakage performance and exceptional durability.
Q: What waterproof ratings can your molds achieve?
A: Our waterproof liquid silicone die can produce components that meet IP67 to IP68 waterproof standards, suitable for submersion applications and harsh environmental sealing requirements.
Q: Can you customize the mold for complex geometries?
A: Absolutely. Our advanced CNC tooling and nano-coating technology enable the production of intricate internal channels, ultra-thin walls, and complex geometries required for modern waterproof electronics and medical devices.
Q: What is your typical lead time for a custom waterproof liquid silicone die?
A: Sample lead time is typically 6 days, with rapid prototyping available for design validation. Full production tooling timelines depend on complexity and cavity count-contact us for a detailed quote.
Q: Do you offer material certification and testing?
A: Yes. Every production batch includes full material traceability, 100% automated pressure leak testing, and 3D laser dimensional inspection. We provide FDA, RoHS, REACH, and ISO 10993 compliance documentation as required.
Partner with Us
As a dedicated LSR mold manufacturer with deep expertise in waterproof sealing applications, we don't just build molds-we engineer solutions that protect your products from moisture, dust, and environmental degradation. Whether you need a prototype for design validation or a high-cavity production tool for million-unit runs, our team delivers precision, reliability, and on-time performance.
Contact us today to discuss your waterproof liquid silicone die requirements.
